EVT290T‑Goshen 10×10 goal‑post triangular truss system with upright columns and overhead header for entrances and branded event displays

10x10 Triangular Truss Goal Post System | EVT290T-Goshen

Original price was: $4,898.00.Current price is: $2,449.00.

10x10 Triangular Truss Goal Post System — Medium-Duty Aluminum Display

Dimensions & Specs
Overall Width: 9.84 ft (3 m)
Overall Height: 9.84 ft (3 m)
Truss Profile: 11.41 in (290 mm) Triangular Truss
Type: Medium-Duty Goal Post System

Construction
Material Type: Aluminum Alloy EN AW-6082 T6
Main Tubing: 1.96 in (50 mm) OD / 0.078 in (2 mm) Wall Thickness
Brace Tubing: 0.78 in (20 mm) Diagonal Bracing / 0.078 in (2 mm) Wall Thickness
Hardware Included: Connecting hardware

Finish & Features
Surface: Aluminum Brush Finish
Certification: TUV Certified
Weight: 180 lb (81.64 kg)

In stock

SKU: EVT290T-GP-10x10-GOSHEN Category:

EVT290T Goal Post Truss System Knowledge Center

Build a Clean, Professional Event Frame.
A 10x10 Triangular Truss Goal Post for Entrances, Photo Ops, Signage, and Branded Displays.

The EVT290T-Goshen is a medium-duty 10x10 triangular-truss goal post system designed for entrances, photo opportunities, step-and-repeat backdrops, signage, lighting, film sets, trade shows, festivals, and outdoor activations. Its modular EVT290T construction creates a lightweight professional frame with a conical connection system for efficient assembly and disassembly.

System Facts

ModelEVT290T-Goshen
SKUEVT290T-GP-10x10-GOSHEN
System TypeTriangular Truss Goal Post
Overall Size9.84 ft W x 9.84 ft H
System Weight180 lb / 81.64 kg
MaterialEN AW-6082 T6
9.84 ftOverall Width
9.84 ftOverall Height
290 mmTriangular Profile
180 lbSystem Weight
2 PeopleSource Setup Crew

System Overview

A Triangular Goal Post Built for Fast, Flexible Event Use.

The Goshen combines a professional 10x10 goal-post footprint with the distinctive visual profile of triangular truss.

10x10 Event Format
Creates a compact rectangular frame for entrances, backdrops, photo opportunities, signage, and lighting.
Medium-Duty EVT290T Construction
Uses 290 mm triangular truss with 50 mm main chords and 20 mm diagonal bracing.
Apex-Down Top Orientation
The top horizontal span is configured apex-down to maintain the intended system geometry and appearance.
Quick Assembly Format
The modular conical connection method supports efficient setup, takedown, and transport.

Applications

Designed for Entrances, Photo Ops, Signage, and Event Displays.

Photo and Step-and-Repeat Backdrops
Creates a defined frame for photography, branded content, and sponsor-wall installations.
Branded Entrances
Provides a visible gateway for trade shows, festivals, activations, and private events.
Signage and Graphic Panels
Supports properly rated graphics and display elements within the approved loading plan.
Lighting and Accessories
Accepts properly rated clamps and accessories for event-lighting applications.
Film Sets and Outdoor Activations
Provides a portable frame for temporary production and event environments.

Who It Is For

A Practical System for Creative and Production Teams.

Event Producers
For entrances, sponsor zones, lighting positions, and branded installations.
Photographers
For step-and-repeat backdrops, photo opportunities, and temporary studio environments.
Exhibit Teams
For trade-show displays that need a distinct triangular-truss frame.
Festival and Activation Teams
For outdoor branding, entryways, and temporary event structures.
Rental Companies
For reusable medium-duty inventory suited to multiple event formats.

Technical Details

Detailed Specifications.

Identification

Product Information

ModelEVT290T-Goshen
SKUEVT290T-GP-10x10-GOSHEN
System TypeMedium-Duty Triangular Truss Goal Post

Physical Dimensions

Overall Size

Overall Width9.84 ft / 3 m
Overall Height9.84 ft / 3 m
Truss Profile11.41 in / 290 mm Triangular
System Weight180 lb / 81.64 kg

Construction

Materials and Tubing

MaterialEN AW-6082 T6 Aluminum
Main Chords50 mm / 1.96 in OD, 2 mm Wall
Diagonal Bracing20 mm / 0.78 in, 2 mm Wall
FinishBrushed Aluminum
CertificationTUV Certified

Installation Planning

Assembly Requirements

Connection TypeConical Couplers, Tapered Pins and R-Clips
Assembly ToolsSteel Truss Hammer
Assembly CrewTwo People Familiar with Truss Structures
Orientation OptionsApex-Down Top Span

System Compatibility

EVT290T, F33, and Standard 290 mm Triangular Truss Systems.

EVT290T-Goshen uses 290 mm triangular truss geometry, 50 mm main chords, and a matching conical connection system. Compatibility requires matching receiver spacing, coupler dimensions, connection geometry, and engineering data.

EVT290T Compatibility
Integrates with compatible EVT290T straight sections, corners, base components, and expansion pieces.
F33 Compatibility
Compatible with matching F33 290 mm triangular truss geometry and conical hardware.
Standard 290 mm Triangular Systems
Verify receiver spacing, connection geometry, apex-down top orientation, and engineering data before combining systems.
50 mm Clamp Compatibility
Main chords accept properly rated standard 50 mm / 2 in clamps.

Modular Expansion

Adapt the Goal Post with Compatible EVT290T Components.

The EVT290T platform allows compatible sections to be added or reconfigured. Any changed configuration must be evaluated before installation.

Adjust Width
Add compatible EVT290T straight sections to create a different engineered span.
Adjust Height
Use compatible sections to create a taller or shorter engineered configuration where appropriate.
Change Orientation
Maintain the apex-down top-span orientation when configuring compatible EVT290T components.
Engineering Review
Modified structures require review for loading, stability, geometry, and site conditions.

Assembly Sequence

Build the Goal Post in a Controlled Sequence.

The source states that two people familiar with truss structures can assemble the system using a steel truss hammer.

01 — Lay Out Components
Arrange the horizontal span, vertical supports, corners, bases, and hardware in their intended positions.
02 — Confirm Orientation
Position the top horizontal truss with the apex facing down and maintain that orientation throughout assembly.
03 — Inspect Every Part
Remove damaged truss, couplers, tapered pins, R-clips, or base components from service.
04 — Assemble the Crossbeam
Connect the horizontal span at ground level using the complete conical hardware set.
05 — Raise and Connect
Use a controlled method appropriate for the complete system weight and site conditions.
06 — Final Inspection
Confirm every connection, base condition, attachment, orientation, and retaining clip before use.

Safety, Loading, and Engineering

Plan Every Installation for Loads, Stability, and Site Conditions.

Do not exceed the allowable load capacity of the complete EVT290T-Goshen configuration.
Distribute loads evenly between the appropriate main chords.
Do not place concentrated loads directly on truss connections unless specifically approved.
Include lighting, signage, graphics, clamps, cables, and all accessories in the total applied load.
Ballast and anchoring requirements depend on the final configuration, attached surfaces, wind exposure, and installation site.
The top horizontal truss must remain apex-down throughout assembly and use.
Inspect all truss sections, bases, and connection hardware before every use.
A licensed professional engineer must review the final structure and loading where required.

Frequently Asked Questions

EVT290T-Goshen Questions.

What are the overall dimensions?
The documented overall size is 9.84 ft wide by 9.84 ft high, using a 290 mm triangular truss profile.
How many people are needed for assembly?
The source states that two people familiar with truss structures can assemble the frame using a steel truss hammer.
What is the required top-truss orientation?
The top horizontal truss is apex-down only. Maintain this orientation during assembly and use.
What applications is it suited for?
It is suited to entrances, photo opportunities, step-and-repeat backdrops, film sets, signage, trade shows, festivals, and outdoor activations.
What truss systems are compatible?
Compatibility includes EVT290T, matching F33 geometry, and standard 290 mm triangular truss systems using matching conical hardware.
Is a 3D model available?
Yes. The product source includes a GLB 3D model for the EVT290T-Goshen.

Planning a 10x10 trade show exhibit?

Contact us for booth configuration, technical drawings, engineering services, graphics, lighting accessories, ballast planning, and freight assistance.
