11x9 Square Truss Oval Arch System Evt290s Oxnard
Evt290s Oxnard Truss System
11x9 Square Truss Oval Arch System Evt290s Oxnard
Evt290s Oxnard Truss System

11x9 Square Truss Oval Arch System | EVT290S-Oxnard

Original price was: $12,404.00.Current price is: $6,202.00.

Medium-Duty Square Aluminum Truss Oval Arch System

Truss System Dimensions
Overall Truss System Height: 11.21 ft (3.41 m)
Overall Truss System Width: 9.14 ft (2.78 m)

Truss Dimensions
Overall Truss Width: 11.41 in (290 mm)
Main Tubing: 1.96 in (50 mm) Outer Diameter Tubing
0.078 in (2 mm) Wall Thickness
Brace Tubing: 0.78 in (20 mm) Diagonal Bracing
0.078 in (2 mm) Wall Thickness

Construction & Features
Material Type: Aluminum Alloy EN AW-6082 T6
Surface: Aluminum Brush Finish
Certification: TUV certified
Included: Connecting hardware
Weight: 232 lb (105.23 kg)

In stock

SKU: EVT290S-OA-11x9-OXNARD Category:

EVT290S Portable Oval Arch Knowledge Center

Frame the Entrance with a Distinctive Curve.
An 11x9 Oval Arch for Floral Design, Luxury Events, Signage, and Mobile Installations.

The EVT290S-Oxnard is a portable square-truss oval arch designed for luxury floral installations, high-end parties, weddings, branded entrances, finish lines, signage, and mobile event production. Its curved EVT290S structure combines a professional architectural profile with a conical connection system for repeatable assembly and takedown.

System Facts

ModelEVT290S-Oxnard
SKUEVT290S-OA-11x9-OXNARD
System TypePortable Oval Arch
Overall Size9.14 ft W x 11.21 ft H
System Weight232 lb / 105.23 kg
MaterialEN AW-6082 T6
9.14 ftOverall Width
11.21 ftOverall Height
290 mmTruss Profile
232 lbSystem Weight
2 PeopleSource Setup Crew

System Overview

A Portable Oval Arch Built for Fast, Repeatable Event Use.

Oval Architectural Profile
Creates a distinctive curved silhouette for entrances, finish lines, and branded event zones.
Portable Event Format
Designed for repeated setup, takedown, transportation, and temporary installation.
EVT290S Construction
Uses medium-duty 290 mm square truss with 50 mm main chords and 20 mm diagonal bracing.
Conical Connections
Tapered pins, couplers, and retaining clips create a secure modular connection system.

Applications

Designed for Luxury Floral and High-End Event Installations.

The oval profile creates a strong architectural foundation for floral designers, wedding planners, event producers, and brands that need a premium focal point with professional truss construction.

Luxury Floral Displays
Supports professionally installed floral treatments, greenery, draping, and decorative elements using properly rated attachment hardware.
Weddings and Ceremonies
Creates a dramatic ceremony arch, sweetheart-table backdrop, or reception focal point.
High-End Parties
Defines entrances, photo moments, VIP areas, and statement installations for premium private events.
Gala and Corporate Events
Provides a refined structural frame for branded décor, lighting, graphics, and sponsor presentations.
Finish Lines and Branded Entrances
Also functions as a professional overhead marker for sports events, activations, and controlled entry points.

Who It Is For

Built for Creative and Production Professionals.

Floral Designers
For large-scale floral arches and decorative installations that need a strong professional framework.
Wedding Planners
For ceremony structures, reception backdrops, and elevated luxury-event designs.
Luxury Event Producers
For statement entrances, immersive décor, VIP zones, and high-end private events.
Rental Companies
For reusable premium-event inventory that can serve weddings, parties, galas, and branded activations.
Brand Activation Teams
For dramatic photo moments, launch events, sponsor displays, and branded arrival experiences.

System Components

A Complete Oval Arch Built from Modular EVT290S Components.

Curved EVT290S Sections
Form the oval crown and curved transition of the arch.
Vertical EVT290S Sections
Create the supporting legs and establish the finished height.
Connection Hardware
Connecting hardware is included with the system.
Modular Expansion
Compatible EVT290S sections can modify or enlarge the system subject to engineering review.

Technical Details

Detailed Specifications.

Identification

Product Information

ModelEVT290S-Oxnard
SKUEVT290S-OA-11x9-OXNARD
System TypePortable Oval Arch Truss System

Physical Dimensions

Overall Size

Overall Width9.14 ft / 2.78 m
Overall Height11.21 ft / 3.41 m
Truss Profile11.41 in / 290 mm

Construction

Materials and Tubing

MaterialEN AW-6082 T6 Aluminum
Main Chords50 mm / 1.96 in OD, 2 mm Wall
Diagonal Bracing20 mm / 0.78 in, 2 mm Wall
FinishBrushed Aluminum
CertificationTUV Certified
System Weight232 lb / 105.23 kg

Installation Planning

Assembly Requirements

Connection TypeConical Couplers, Tapered Pins and R-Clips
Assembly ToolsSteel Hammer
Assembly CrewTwo People Familiar with Truss Structures

System Compatibility

EVT290S, F34, and Standard 290 mm Square Truss Systems.

EVT290S-Oxnard uses 290 mm square truss geometry, 50 mm main chords, and a matching conical connection system. Compatibility requires matching receiver spacing, coupler dimensions, and engineering data.

EVT290S Compatibility
Integrates with compatible EVT290S straight sections, curved sections, junctions, and expansion components.
F34 Compatibility
Compatible with matching F34 290 mm square truss geometry and conical hardware.
Standard 290 mm Square Systems
Verify receiver spacing, connection geometry, and engineering data before combining systems.
50 mm Clamp Compatibility
Main chords accept properly rated standard 50 mm / 2 in clamps.

Modular Expansion

Adapt the Arch with Compatible EVT290S Components.

The source states that the system can be expanded by adding compatible EVT290S pieces. Any modified configuration must be reviewed for geometry, stability, loading, and site conditions.

Increase Overall Size
Add compatible straight or curved components to develop a larger engineered configuration.
Change the Entry Profile
Reconfigure compatible components for different event footprints, subject to engineering review.
Expand Rental Inventory
Use shared EVT290S components across compatible systems and future builds.
Engineering Review
Modified structures require professional review before installation or use.

Assembly Sequence

Build the Oval Arch in a Controlled Sequence.

Assembly should be completed by two people familiar with truss structures. Inspect all components before use and follow the supplied system drawing and approved installation plan.

01 — Lay Out Components
Arrange curved sections, vertical sections, and hardware in their intended positions.
02 — Inspect Every Part
Remove damaged truss, couplers, pins, or retaining clips from service.
03 — Assemble the Crown
Connect the curved crown sections using the complete conical hardware set.
04 — Assemble the Legs
Build the vertical supports and verify matching orientation.
05 — Raise and Connect
Use a controlled method appropriate for the system weight and final installation plan.
06 — Final Inspection
Confirm every connection, retaining clip, attachment, and support condition before use.

Safety & Engineering

Every Booth Installation Requires Project-Specific Load Planning.

Allowable loads depend on the full booth configuration, load distribution, support conditions, base design, ballast, venue requirements, attached equipment, graphics, and environmental forces.

Do not exceed the allowable load capacity of the complete Oxnard oval arch configuration.
Distribute loads evenly between the appropriate truss chords and approved attachment locations.
Inspect all truss sections, welds, junctions, couplers, pins, clips, and bases before every setup.
Do not use any damaged, bent, cracked, deformed, or incomplete component.
Account for transverse forces, including wind loads, when planning the structure.
Use appropriate ballast or anchorage as required by the venue and engineered plan.
Floral materials, greenery, draping, lighting, and decorative elements must be included in the total applied load and installed with properly rated hardware.
A licensed professional engineer must review the final structure and loading where required.

Frequently Asked Questions

EVT290S-Oxnard Questions.

What are the overall dimensions?
The documented overall size is approximately 9.14 ft wide by 11.21 ft high, with a 290 mm truss profile.
How many people are needed for assembly?
The source states that two people familiar with truss structures can assemble the system.
What assembly tool is required?
The source identifies a steel hammer for the conical connection system.
Can the arch be expanded?
Yes. Compatible EVT290S pieces may be added, but the modified design must be reviewed for geometry, loading, stability, and site conditions.
What is included?
The source specifies connecting hardware as included.

Planning a 11x9 trade show exhibit?

Contact us for booth configuration, technical drawings, engineering services, graphics, lighting accessories, ballast planning, and freight assistance.
