Name: 30x30 Suspended Triangle Truss System | SkyGrid-TRI600
Brand: Evolve Truss
SKU: SkyGrid-TRI-30x30-600
Price: 7134.00 USD
Availability: InStock

SkyGrid System Knowledge Center

A 30x30 Suspended Triangle.
Built for Large Overhead Layouts.

The SkyGrid-TRI600 is a modular 30x30 suspended triangular truss grid built from EVT290S medium-duty square aluminum truss. Designed for overhead lighting, AV equipment, signage, scenic elements, exhibitions, studios, retail displays, and event staging, it creates a large three-sided framework while keeping the floor area open.

System Facts

Model SkyGrid-TRI600

SKU SkyGrid-TRI-30x30-600

System Type Suspended Triangular Grid

Overall Size 29.53 x 29.53 ft

Inside Size 26.23 x 26.23 ft

System Weight 366 lb

30x30 ft Nominal Grid

290 mm Square Truss Profile

366 lb System Weight

Conical Connection System

2 Riggers Min. Qualified Crew

System Overview

A Large Triangular Overhead Framework Built from Square Truss.

The SkyGrid-TRI600 uses EVT290S square truss sections arranged in a triangular suspended layout. The triangle describes the overall grid shape, while each structural member uses a 290 mm square truss profile.

Triangular Grid Layout

Creates a distinctive three-sided overhead structure for lighting, signage, scenic elements, and AV equipment.

Open Floor Space

Keeps structural members overhead so the area below remains available for staging, exhibits, displays, cameras, and guest circulation.

EVT290S Construction

Uses medium-duty 290 mm square aluminum truss with 50 mm main chords and welded diagonal bracing.

Expandable Modular Design

Compatible EVT290S components can be added to create alternate or larger layouts when supported by the required engineering.

Common Applications

Designed for Large Overhead Production Environments.

The large triangular footprint provides a recognizable overhead shape for temporary and permanent-style professional installations.

Exhibitions and Trade Shows

Suspend lighting, signage, banners, and branded elements above large exhibit areas.

Retail Displays

Create a distinctive overhead framework for product lighting and visual merchandising.

Broadcast and Photography Studios

Organize lighting, cameras, modifiers, and production accessories above the working area.

Live Event Staging

Support engineered lighting and AV layouts above stages and performance spaces.

Experiential Installations

Create a large overhead visual boundary for branded and interactive environments.

Who It’s For

Built for Professionals Managing Suspended Truss Systems.

Best suited for qualified teams experienced with overhead truss, lifting, load planning, venue requirements, and suspended equipment.

Production Companies

For large lighting, scenic, AV, and event installations.

Rigging Companies

For engineered suspension plans using approved venue points and lifting equipment.

Exhibit Houses

For overhead booth lighting, signage, and branded display structures.

Broadcast and Studio Teams

For repeatable overhead lighting and equipment layouts.

Retail and Experiential Designers

For suspended visual elements and large-format installations.

Venue Technical Departments

For approved installations coordinated with venue rigging capacity and procedures.

System Package

Components for the Standard TRI600 Grid.

The package includes the truss sections and connecting hardware required to assemble the standard suspended triangular framework.

EVT290S Straight Truss Sections

Form the three primary sides of the suspended grid.

Triangle Junction Components

Connect the straight sections at the three corners of the grid.

Connecting Hardware

Includes the conical couplers, tapered pins, retaining clips, and applicable hardware.

3D Technical Drawing

A detailed drawing with dimensions and part labels is included for assembly reference.

Suspension and lifting hardware are project-specific.

Motors, chain falls, shackles, span sets, slings, venue rigging points, clamps, and secondary safeties must be selected for the approved rigging plan.

Technical Reference

Complete System Specifications

Overall dimensions, internal dimensions, truss construction, finish, weight, compatibility, and setup requirements.

Identification

System Details

ModelSkyGrid-TRI600

SKUSkyGrid-TRI-30x30-600

BrandEvolve Truss

System TypeSuspended Triangular Truss Grid

Grid Dimensions

Overall Size

Overall Grid Width29.53 ft / 9 m

Overall Grid Length29.53 ft / 9 m

Inside Grid Width26.23 ft / 8 m

Inside Grid Length26.23 ft / 8 m

System Weight366 lb / 166.01 kg

Truss Construction

Materials

Truss SeriesEVT290S Medium-Duty Square Truss

Truss Profile290 mm / 11.41 in Square

MaterialEN AW-6082 T6 Aluminum

Main Chord Tubing50 mm OD / 2 mm Wall

Diagonal Brace Tubing20 mm OD / 2 mm Wall

Installation Planning

Assembly & Rigging Requirements

Connection TypeConical Couplers, Tapered Pins and R-Clips

Assembly ToolsSteel Hammer and M10 Hex Allen Wrench

Assembly CrewMinimum 2 Qualified Riggers; 3 Recommended

Lifting EquipmentRated Motors, Chain Falls and/or Other Approved Lifting Equipment

Assembly LocationGround Level Before Lifting

System Compatibility

EVT290S, F34, and Standard 290 mm Square Truss Systems.

The SkyGrid-TRI600 uses 290 mm square truss geometry, 50 mm main chords, and a matching conical connection system. Compatibility requires matching receiver spacing, coupler dimensions, connection geometry, and engineering data.

EVT290S Compatibility

Integrates with compatible EVT290S straight sections, corners, junctions, and expansion components.

F34 Compatibility

Compatible with matching F34 290 mm square truss geometry and conical hardware.

Standard 290 mm Square Systems

Verify receiver spacing, connection geometry, and engineering data before combining systems.

50 mm Clamp Compatibility

Main chords accept properly rated standard 50 mm / 2 in clamps.

Assembly Overview

Assemble at Ground Level. Inspect Before Lifting.

Assemble the complete triangle at ground level using a minimum of two qualified riggers, with three recommended. Suspension, lifting, leveling, and final positioning require a qualified rigging crew using rated motors, chain falls, or other approved lifting equipment.

01 — Lay Out Components

Arrange the straight sections, junctions, and connection hardware in the triangular configuration.

02 — Inspect Every Part

Check chords, braces, welds, receivers, couplers, pins, clips, and bolts.

03 — Connect the Three Sides

Install the conical couplers and connect the straight truss sections to the corner junctions.

04 — Secure Every Connection

Fully seat each tapered pin, retaining clip, and applicable junction fastener.

05 — Attach Approved Rigging

Install the project-specific lifting and suspension equipment according to the engineered plan.

06 — Lift with Qualified Riggers

Use a qualified rigging crew and rated lifting equipment to raise, level, and position the complete system while monitoring every pick point.

Safety and Engineering

Suspended Structures Require Project-Specific Load Calculations.

Allowable load depends on the number and location of pick points, span conditions, truss orientation, attached equipment, load distribution, lifting equipment, venue structure, and the complete rigging design.

Do not exceed the allowable load capacity established for the complete SkyGrid-TRI600 installation.

Inspect the complete grid and every connection before each use and before every lift.

Do not use any truss, junction, coupler, pin, clip, or fastener showing damage or deformation.

Use independently rated secondary safeties for overhead fixtures and accessories where required.

Verify all venue rigging points, motors, shackles, slings, and span sets are rated for the complete load.

Overhead assembly, lifting, and installation must be performed by qualified rigging professionals.

A qualified rigging crew and rated lifting equipment are required for every SkyGrid installation.

A licensed professional engineer must review the final rigging plan where required.

System Questions

Frequently Asked Questions

Is the truss itself triangular?

No. The overall suspended grid is triangular, but the structural members are EVT290S square truss with a 290 mm profile.

What are the overall dimensions?

The listed overall width and length are 29.53 ft, or 9 m. The listed inside width and length are 26.23 ft, or 8 m.

How many people are needed for setup?

The source identifies a typical crew of 2 to 3 people who are familiar with the system. Suspended installation and lifting must still be completed by qualified personnel.

Can the grid be expanded?

Yes. Compatible EVT290S sections can be added to create larger or alternate layouts, subject to engineering and rigging review.

Is an engineering report included?

A detailed 3D technical drawing is included. An engineering report is available as a separate service.

Planning a large suspended triangular grid?

Contact us for grid configuration, compatible components, technical drawings, engineering services, rigging planning, and freight assistance.
