EVT290I-2WCV 2-Way 90-Degree Vertical Corner for I-Beam Truss, high-strength and reliable truss connector

EVT290I-2WCV | 90° Corner

Original price was: $389.00.Current price is: $259.00.

EVT290I-2WCV | 90° 2-Way Vertical Corner
Medium-Duty I-Beam Aluminum Truss
90-Degree 2-Way Vertical Corner

Dimensions
Overall Truss Length: 1.64 ft (0.5 m)
Overall Truss Width: 11.41 in (290 mm)

Construction
Material Type: Aluminum Alloy EN AW-6082 T6
Main Tubing: 1.96 in (50 mm) Outer Diameter
0.08 in (2 mm) Wall Thickness
Brace Tubing: 0.78 in (20 mm) Diagonal Bracing
0.08 in (2 mm) Wall Thickness

Finish & Features
Surface: Aluminum Brush Finish
Certification: TUV certified
Included: Connecting hardware
Weight: 7.0 lb (3.17 kg)

In stock

SKU: EVT290I-2WCV Category:

EVT290I I-Beam Truss Knowledge Center

A 2-Way 90-Degree Vertical Corner.
Built for Medium-Duty I-Beam Truss Layouts.

The EVT290I-2WCV is a medium-duty 2-way vertical corner designed for 290 mm I-beam aluminum truss systems. Its 90-degree geometry creates vertical direction changes for lighting rigs, trade-show structures, retail displays, staging systems, and other modular event installations.

Product Facts

ModelEVT290I-2WCV
Corner Type2-Way Vertical 90°
Overall Size500 x 290 x 500 mm
MaterialEN AW-6082 T6 Aluminum
FinishBrushed Aluminum
Weight7 lb / 3.17 kg
90°Vertical Corner
290 mmI-Beam Profile
50 mmMain Tubing
20 mmDiagonal Bracing
7 lbProduct Weight

Product Overview

A Clean Vertical Direction Change for 290 mm I-Beam Truss.

The EVT290I-2WCV creates a rigid 90-degree vertical corner while maintaining the compact profile and conical connection system of the EVT290I truss family.

Vertical 90-Degree Geometry
Creates a clean transition between horizontal and vertical I-beam truss runs.
Medium-Duty Construction
Designed for professional stages, lighting rigs, exhibits, and event structures.
6082-T6 Aluminum
Combines structural strength, corrosion resistance, and low product weight.
Conical Connection System
Supports quick, repeatable assembly using matching couplers, pins, and retaining clips.

Common Applications

Designed for Vertical Corners in Modular Structures.

01
Lighting Rigs
Create vertical transitions in compact lighting and fixture-support structures.
02
Trade Show Booths
Add clean 90-degree corners to branded exhibit and display systems.
03
Retail Displays
Build modular frames, towers, signage structures, and product displays.
04
Stage Structures
Use in reviewed medium-duty support and scenic framing layouts.
05
Outdoor Event Structures
Suitable for engineered temporary structures where corrosion-resistant aluminum is preferred.

Who It’s For

Built for Professional Event and Exhibit Teams.

Lighting Designers
For compact vertical transitions in medium-duty lighting systems.
Exhibit Builders
For modular booth, tower, and display structures.
Event Production Companies
For repeat-use stage, scenic, and branded event frameworks.
Rental Companies
For expanding EVT290I I-beam truss inventory with a vertical corner.
Retail Fabricators
For temporary and permanent merchandising structures.
Riggers and Installers
For reviewed structures requiring a precise 2-way vertical corner.

Product Features

Compact Geometry. Professional Truss Construction.

2-Way Vertical Corner
Creates a 90-degree change in direction between two I-beam truss runs.
290 mm Profile
Matches the EVT290I I-beam truss system profile.
50 mm Main Tubing
Uses 1.96 in main tubing with a 2 mm wall thickness.
20 mm Bracing
Diagonal bracing uses 0.78 in tubing with a 2 mm wall thickness.
Brushed Aluminum Finish
Provides a clean appearance and corrosion-resistant surface.
TUV-Certified Construction
Manufactured according to TUV specifications.

Included Components

Vertical Corner and Connecting Hardware.

The product includes the corner section and the connecting hardware required for its matching conical truss connections.

1 EVT290I-2WCV Corner
Medium-duty 2-way 90-degree vertical I-beam truss corner.
Conical Receivers
Integrated connection points for the matching truss system.
Conical Couplers
Included for secure truss-to-corner assembly.
Connection Hardware
Matching pins and retaining clips are included with the connection set.

Technical Reference

Complete Product Specifications

Identification

Product Details

ModelEVT290I-2WCV
SKUEVT290I-2WCV
BrandEvolve Truss
Product Type2-Way 90-Degree Vertical I-Beam Corner

Dimensions and Weight

Overall Size

Width500 mm / 19.69 in
Height290 mm / 11.41 in
Depth500 mm / 19.69 in
Nominal Truss Length0.5 m / 1.64 ft
Weight7 lb / 3.17 kg

Construction

Material and Tubing

MaterialEN AW-6082 T6 Aluminum
Main Tubing50 mm / 1.96 in OD, 2 mm Wall
Brace Tubing20 mm / 0.78 in, 2 mm Wall
FinishBrushed Aluminum
CertificationTUV Certified

Connection and Compatibility

System Fit

Connection TypeConical Connection System
Included HardwareConical Receivers, Couplers, Pins and Retaining Clips
Truss CompatibilityEVT290I I-Beam Aluminum Truss System

Truss Compatibility

Designed for the EVT290I I-Beam Truss System.

Confirm the mating truss sections use the same 290 mm I-beam geometry and matching conical connection system before assembly.

EVT290I System
Directly compatible with the EVT290I 290 mm I-beam truss family.
Matching Conical Geometry
Requires compatible receiver spacing, couplers, pins, and retaining clips.
50 mm Clamp Support
The main tubing supports compatible 50 mm / 1.96 in clamps.
Verify Before Mixing
Exact fit with other brands or I-beam systems should be confirmed before use.

Assembly Overview

Align the Corner. Install Every Coupler, Pin, and Retaining Clip.

01 — Inspect All Components
Check the corner, truss sections, couplers, pins, and retaining clips for damage.
02 — Confirm Orientation
Position the vertical corner in the correct 90-degree direction.
03 — Align the First Truss
Bring the matching truss section into alignment without forcing the geometry.
04 — Install the Couplers
Seat every required conical coupler fully into the matching receivers.
05 — Install Pins and Clips
Drive each pin fully into place and secure every retaining clip.
06 — Final Inspection
Verify alignment, connection security, support conditions, and complete-system stability.

Safety and Engineering

Corner Capacity Depends on the Complete Truss Structure.

Final capacity depends on connected spans, support conditions, load direction, fixture placement, connection condition, and project-specific engineering.

Do not exceed the allowable capacity of the complete truss system.
Do not support loads directly from the truss connection points.
Inspect the corner and every connection component before use.
Do not use the product if any chord, brace, receiver, coupler, pin, or retaining clip is damaged.
Do not drop, drag, or throw truss sections or corners during handling.
Assembly must be performed by trained personnel familiar with aluminum truss systems.

Product Questions

Frequently Asked Questions

What type of corner is this?

It is a 2-way 90-degree vertical corner for the EVT290I I-beam aluminum truss system.

What are the overall dimensions?

The corner measures 500 x 290 x 500 mm, approximately 19.69 x 11.41 x 19.69 in.

What hardware is included?

The product includes connecting hardware for the conical connection system, including conical receivers and couplers.

What material is used?

It is manufactured from EN AW-6082 T6 aluminum with a brushed finish.

What clamps fit the main tubing?

Compatible 50 mm / 1.96 in clamps fit the main tubing.

Can loads be attached at the connection?

No. Loads should not be supported directly from the truss connection points.

Need a vertical corner for your EVT290I structure?

Contact us for compatibility checks, layout support, additional hardware, engineering coordination, and quantity pricing.
