What is the difference between the EVT220S-Altura and the EVT220T-Alpine booth systems?

The EVT220S-Altura uses the EVT220S square truss profile — four chord tubes arranged in a square cross-section. The EVT220T-Alpine uses the EVT220T triangular truss profile — three chord tubes in a triangle. Both are 220mm systems with 35mm chord tubing and conical connections, and both require 35mm clamps. The visual difference is the overhead cross-section: square gives a clean boxy geometric look, triangular gives an angular geometric look. Both are compatible with F24 and standard 220mm systems and are expandable with their respective component lines.

What happens structurally if I use a rear scrim or large banner on this booth?

A rear scrim or banner creates a sail effect in any environment with air movement — from HVAC airflow in a convention center to outdoor wind. This lateral force can tip the structure if it is not anchored. The EVT220S-Altura requires 800 lb of ballast on each corner — or direct anchorage to a concrete slab — whenever a rear scrim or banner is in use. Do not set up a banner configuration without meeting this ballast requirement, and always have a licensed structural engineer review the full configuration before loading people or equipment nearby.

Can I reconfigure this booth into shapes other than a 10x10 square?

Yes. By adding 3-way or 4-way junction blocks from the EVT220S series, you can transform the basic square into an L-shape, a T-shape, or a 3D lighting grid. Adding 0.5m, 1.0m, or 2.0m straight sections to the vertical columns raises the overall height for taller ceiling configurations. All modifications must stay within the EVT220S system's load ratings and should be reviewed by a licensed structural engineer before use.

Aluminum Truss, F24 Trussing, Square Truss, Global Truss, Tradeshow Display, small trade show booth, truss genius, sidus

10x10 Trade Show Exhibit Display Booth | EVT220S-Altura

Original price was: $11,766.00.Current price is: $5,883.00.

EVT220S-Altura — 10x10 Aluminum Trade Show Booth Kit – Exhibit Display System

Dimensions & Specs
Footprint: 10 ft x 10 ft (3.04 m x 3.04 m)
Truss Profile: 8.66 in (220 mm) Square Display Truss
Type: Modular Trade Show Booth Kit
Compatibility: Fits F24, EVT220S, and all standard 220mm Square Truss systems

Construction
Material Type: Aluminum Alloy EN AW-6061 T6
Main Tubing: 1.37 in (35 mm) OD / 0.08 in (2 mm) Wall Thickness
Brace Tubing: 0.39 in (10 mm) Diagonal Bracing
Connection Type: Conical Connection System (Includes Couplers, Tapered Pins, and R-Clips)

Finish & Features
Surface: Aluminum Brush Finish
Application: Trade Show Exhibits, Retail Pop-Ups, Indoor Events
Weight: 166 lb (75.30 kg)

In stock

SKU: EVT220S-TSB-10x10-ALTURA Categories: 10x10 Trade Show Booths, Engineered Truss Systems

Product Details & Resources

EVT220S Booth System Knowledge Center

A Complete 10x10 Square Truss Booth.
Built for Modular Trade Show and Display Environments.

The EVT220S-Altura is a complete 10x10 modular square aluminum truss booth built from EVT220S 220 mm square display truss. It provides a professional open-frame structure for trade shows, branded environments, retail displays, lighting accents, and signage in its fixed 10x10 configuration.

System Facts

ModelEVT220S-Altura

SKUEVT220S-TSB-10x10-ALTURA

Booth Footprint10x10 ft

Overall Height9.84 ft / 3 m

Truss SeriesEVT220S

System Weight166 lb / 75.30 kg

10x10 ftBooth Footprint

220 mmSquare Profile

166 lbSystem Weight

35 mmMain Chords

ConicalConnection System

System Overview

A Modular 10x10 Square Truss Booth Built for Trade Shows, Retail, and Branded Environments.

The EVT220S-Altura combines a 10x10 footprint, 9.84 ft overall height, and modular conical construction in one complete fixed booth configuration.

10x10 Booth Footprint

Provides a large branded display area for inline or island-style configurations.

Fixed 10x10 Layout

Designed to assemble as the specified 10x10 booth configuration shown for this system.

Light-Duty EVT220S Truss

Uses 220 mm square truss with 35 mm main chords for a compact exhibit profile.

Reusable Booth System

The booth can be transported, disassembled, and rebuilt in the same 10x10 configuration for future events.

Common Applications

Designed for Trade Shows and Branded Environments.

Trade Show Exhibits

Create a branded overhead structure for 10x10 exhibit spaces.

Product Displays

Frame product demonstrations, shelving, graphics, and display counters.

Branded Activations

Support banners, signage, lighting, and branded visual elements.

Temporary Retail

Build pop-up and promotional environments with reusable truss components.

Corporate Events

Create registration, sponsor, demonstration, or hospitality structures.

Who It’s For

Built for Teams That Need A Reusable 10x10 Display System.

Exhibit Builders

For modular client booths and repeat trade-show installations.

Marketing Agencies

For branded activations, launches, and promotional environments.

Event Production Companies

For corporate displays, sponsor areas, and temporary event structures.

Rental Companies

For repeat-use 10x10 booth inventory that can be deployed across multiple events.

Retail Brands

For pop-up shops, product showcases, and temporary branded spaces.

In-House Exhibit Teams

For companies attending multiple events with reusable components.

Configuration

One Complete System. One Specified 10x10 Booth Layout.

The EVT220S-Altura is designed to assemble in one specified 10x10 booth configuration. The supplied component set does not convert into a second booth design, inline variation, island variation, L-shape, or alternate structural layout.

Single 10x10 Layout

All included components are intended for the specified 10x10 booth arrangement shown for the system.

Repeatable Assembly

The booth can be disassembled, transported, and rebuilt in the same approved configuration.

No Alternate Booth Designs

The included kit does not create a second booth design or a smaller island-style configuration.

System Expansion

Larger or different layouts require separately selected EVT220S components and a new engineered system design.

Technical Reference

Complete System Specifications

Identification

System Details

ModelEVT220S-Altura

SKUEVT220S-TSB-10x10-ALTURA

BrandEvolve Truss

System Type10x10 Light-Duty Square Aluminum Truss Booth

Dimensions and Weight

Overall Size

Booth Footprint10x10 ft / 3.04x3.04 m

Overall Width118.11 in / 3 m

Overall Depth118.11 in / 3 m

Overall Height9.84 ft / 3 m / 118.11 in

System Weight166 lb / 75.30 kg

Truss Construction

EVT220S System

Truss ProfileEVT220S 220 mm / 8.66 in Square

Main Chords35 mm / 1.37 in OD, 2 mm Wall

Diagonal Brace Tubing10 mm / 0.39 in

MaterialEN AW-6061 T6 Aluminum

FinishBrushed Aluminum

CertificationTUV Specifications

Assembly and Compatibility

System Requirements

Connection TypeConical Couplers, Tapered Pins and R-Clips

Assembly Crew3 to 4 People

Assembly ToolSmall Hammer

System Compatibility

EVT220S, F24, and Standard 220 mm Square Truss Systems.

The EVT220S-Altura uses standard 220 mm square display truss geometry and a matching conical connection system. It is compatible with EVT220S, F24, and standard 220 mm square truss systems using matching coupler and receiver geometry.

EVT220S Compatibility

Integrates with compatible EVT220S straight sections, junctions, corners, and expansion components.

F24 Compatibility

Compatible with matching F24 220 mm square truss geometry and conical hardware.

Standard 220 mm Systems

Compatible with standard 220 mm square truss systems using matching connection geometry.

35 mm Clamp Requirement

Use properly rated 35 mm clamps only. Standard 50 mm clamps will not fit the main chords.

Assembly Overview

Build the Crown First. Then Add the Vertical Supports.

The system is typically assembled by three to four people using a steel hammer for the tapered-pin conical connections.

01 — Organize Components

Lay out straight sections, corners, bases, couplers, pins, and R-clips by position.

02 — Build the Overhead Crown

Assemble the upper 10x10 rectangular structure at floor level.

03 — Install Base Components

Position and secure the bases according to the specified 10x10 booth layout.

04 — Add Vertical Sections

Raise the crown in a controlled sequence and install the vertical supports.

05 — Lock Every Connection

Verify all couplers, tapered pins, and R-clips are fully seated.

06 — Final Inspection

Confirm plumb, level, ballast, clearances, and attachment security before use.

Published Load and Stability Reference

Loading and Ballast Must Match the Final Configuration.

Distributed Load Reference

Approx. 160 lb per linear foot, subject to span, support positions, load placement, and engineering review.

Rear Scrim or Banner

A rear scrim or banner creates a sail effect and changes the lateral loading on the booth.

Required Ballast

Use 800 lb of ballast at each corner, or direct engineered anchorage to a concrete slab, whenever a rear scrim or banner is installed.

Engineering Review

A licensed professional engineer must review the completed configuration, loads, and anchorage before use.

Safety and Engineering

Exhibit Loads, Ballast, and Overhead Elements Must Be Evaluated as One System.

Final capacity depends on the booth configuration, attached signs, lighting, graphics, monitors, rigging points, ballast, floor conditions, and venue requirements.

Use only complete, undamaged EVT220S-compatible components and connection hardware.

Use 35 mm clamps only; standard 50 mm clamps will not fit the main chords.

Do not apply loads directly at truss connections unless specifically allowed by the engineering data.

Evaluate all graphics, monitors, lighting, shelving, and suspended elements before installation.

Provide ballast or anchoring suitable for the actual booth configuration and venue conditions.

Assembly should be performed by trained personnel following an approved installation plan.

System Questions

Frequently Asked Questions

How many people are needed for assembly?

The listed assembly crew is three to four people.

What tool is required?

A steel hammer is used to seat and remove the tapered pins in the conical connection system.

Can the booth be configured in different layouts?

No. The EVT220S-Altura is designed to assemble in one specified 10x10 booth configuration.

What clamps fit this truss?

Use 35 mm clamps only. Standard 50 mm clamps will not fit the EVT220S main chords.

Are CAD files available?

STEP and DWG files are available upon request.

Is engineering available?

An engineering report is available as a separate service and should be requested during purchase.

Need a reusable 10x10 truss exhibit?

Contact us for assembly support, graphics and lighting planning, additional EVT220S components, engineering, CAD files, and quantity pricing.
