20x20 Trade Show Exhibit Display Booth EVT290S-Cabria

20x20 Trade Show Exhibit Display Booth | EVT290S-Cabria

Original price was: $53,084.00.Current price is: $26,542.00.

Medium-Duty Square Aluminum Truss Booth – Cross Signage

Truss System Dimensions
Overall Truss System Height: 13.41 ft (4.08 m)
Overall Truss System Width: 20 ft (6 m)
Overall Truss System Length: 20 ft (6 m)
Approximate Coverage: 400 sq ft

Truss Dimensions
Overall Truss Width: 11.41 in (290 mm)
Main Tubing: 1.96 in (50 mm) Outer Diameter Tubing
0.078 in (2 mm) Wall Thickness
Brace Tubing: 0.78 in (20 mm) Diagonal Bracing
0.078 in (2 mm) Wall Thickness

Construction & Features
Material Type: Aluminum Alloy EN AW-6082 T6
Surface: Aluminum Brush Finish
Certification: TUV certified
Included: Connecting hardware
Weight: 995 lb (451.32 kg)

In stock

SKU: EVT290S-TSB-20x20-CABRIA Category:

EVT290S Cross-Signage Booth System Knowledge Center

Turn the Center of a 20x20 Exhibit into a Branding Landmark.
A 13.41-Foot Square-Truss Structure with Cross-Signage Attachment Options.

The EVT290S-Cabria is a medium-duty 20x20 square aluminum truss booth designed around cross-signage attachment options for high-visibility branding. Built from EVT290S 290 mm truss, the system provides approximately 400 sq ft of coverage and may be used as an island or inline exhibit.

System Facts

ModelEVT290S-Cabria
SKUEVT290S-TSB-20x20-CABRIA
System Dimensions20x20 ft
Overall Height13.41 ft / 4.08 m
DesignCross Signage
System Weight995 lb / 451.32 kg
20x20 ftBooth Footprint
13.41 ftOverall Height
400 sq ftApprox. Coverage
3–4Typical Crew
Cross SignageBranding Feature

System Overview

A Full 20x20 Exhibit. Centered Around Elevated Cross Signage.

The EVT290S-Cabria combines a 20x20 ft footprint with a 13.41 ft overall height and approximately 400 sq ft of coverage. Its cross-signage structure creates elevated attachment points for branding while preserving open exhibit space below.

Cross-Signage Options
The elevated center structure is designed for branding attachments and high-visibility signage.
Island or Inline Use
The system may be used as an island or inline booth when the final layout complies with venue requirements.
Approximately 400 sq ft
The full-size footprint provides room for displays, demonstrations, lighting, and visitor circulation.
Expandable EVT290S System
Additional EVT290S pieces may be added to create a larger engineered structure.

Common Applications

Designed for Trade Shows and Branded Environments.

01
Trade Show Exhibits
Create a branded overhead structure for 20x20 exhibit spaces.
02
Product Displays
Frame product demonstrations, shelving, graphics, and display counters.
03
Branded Activations
Support banners, signage, lighting, and branded visual elements.
04
Temporary Retail
Build pop-up and promotional environments with reusable truss components.
05
Corporate Events
Create registration, sponsor, demonstration, or hospitality structures.

Who It’s For

Built for Teams That Need A Reusable 20x20 Display System.

Exhibit Builders
For modular client booths and repeat trade-show installations.
Marketing Agencies
For branded activations, launches, and promotional environments.
Event Production Companies
For corporate displays, sponsor areas, and temporary event structures.
Rental Companies
For repeat-use 20x20 booth inventory that can be deployed across multiple events.
Retail Brands
For pop-up shops, product showcases, and temporary branded spaces.
In-House Exhibit Teams
For companies attending multiple events with reusable components.

System Design

One Cross-Signage Component Set. Suitable for Island or Inline Booth Use.

The EVT290S-Cabria is described for island or inline booth use. The final arrangement must follow the supplied technical drawing and receive structural review for venue conditions, loads, signage, lighting, and access requirements.

Cross-Signage Structure
The included component set creates the documented elevated branding framework.
Island Booth Use
The open structure may be used as an island exhibit when reviewed for circulation and venue conditions.
Inline Booth Use
The system may also be used inline when the final configuration complies with venue height and access rules.
Future Expansion
Additional EVT290S components may be selected separately for a larger engineered structure.

Technical Reference

Complete System Specifications

Identification

System Details

ModelEVT290S-Cabria
SKUEVT290S-TSB-20x20-CABRIA
BrandEvolve Truss
System Type20x20 Medium-Duty Square Aluminum Truss Booth - Cross Signage

Dimensions and Weight

Overall Size

Booth Footprint20x20 ft / 6x6 m
DesignCross Signage
CoverageApproximately 400 sq ft
Structure4-Column Island with 20x20 Cross-Signage Structure
CoverageApproximately 200 sq ft
Overall Width20 ft / 6 m
Overall Depth20 ft / 6 m
Overall Height13.41 ft / 4.08 m
System Weight995 lb / 451.32 kg

Truss Construction

EVT290S System

Truss ProfileEVT290S 290 mm / 11.41 in Square
Main Chords50 mm / 1.96 in OD, 2 mm Wall
Brace Tubing20 mm / 0.78 in Diagonal, 2 mm Wall
MaterialEN AW-6082 T6 Aluminum
FinishBrushed Aluminum
CertificationTUV Specifications

Installation Planning

Assembly Requirements

Connection TypeConical Couplers, Tapered Pins and R-Clips
Assembly ToolsSteel Hammer and M10 Hex Allen Wrench
Assembly Crew3 to 4 People and/or a Qualified Rigging Crew as Required
Access and Rigging EquipmentPersonnel Lifts and/or Rigging Equipment Appropriate for the Final Assembly Method

System Compatibility

EVT290S, F34, and Standard 290 mm Square Truss Systems.

The EVT290S-Cabria uses 290 mm square truss geometry, 50 mm main chords, and a matching conical connection system. Compatibility requires matching receiver spacing, coupler dimensions, and engineering data.

EVT290S Compatibility
Integrates with compatible EVT290S straight sections, corners, junctions, and expansion components.
F34 Compatibility
Compatible with matching F34 290 mm square truss geometry and conical hardware.
Standard 290 mm Square Systems
Verify receiver spacing, connection geometry, and engineering data before combining systems.
50 mm Clamp Compatibility
Main chords accept properly rated standard 50 mm / 2 in clamps.

Assembly Overview

Build the Crown First. Then Add the Vertical Supports.

The system is typically assembled by three to four people using a steel hammer for the tapered-pin conical connections.

01 — Organize Components
Lay out straight sections, corners, bases, couplers, pins, and R-clips by position.
02 — Build the Overhead Crown
Assemble the cross-signage overhead structure at floor level.
03 — Install Base Components
Position and secure the bases according to the specified 20x20 booth layout.
04 — Add Vertical Sections
Raise the crown in a controlled sequence and install the vertical supports.
05 — Lock Every Connection
Verify all couplers, tapered pins, and R-clips are fully seated.
06 — Final Inspection
Confirm plumb, level, ballast, clearances, and attachment security before use.

Safety and Engineering

Exhibit Loads, Ballast, and Overhead Elements Must Be Evaluated as One System.

Final capacity depends on the booth configuration, attached signs, lighting, graphics, monitors, rigging points, ballast, floor conditions, and venue requirements.

Use only complete, undamaged EVT290S-compatible components and connection hardware.
Use 35 mm clamps only; standard 50 mm clamps will not fit the main chords.
Do not apply loads directly at truss connections unless specifically allowed by the engineering data.
Evaluate all graphics, monitors, lighting, shelving, and suspended elements before installation.
Provide ballast or anchoring suitable for the actual booth configuration and venue conditions.
Assembly should be performed by trained personnel following an approved installation plan.

System Questions

Frequently Asked Questions

How many people are needed for assembly?

The listed assembly crew is three to four people.

What tool is required?

A steel hammer is used to seat and remove the tapered pins in the conical connection system.

Can the booth be configured in different layouts?

The EVT290S-Cabria may be used as an island or inline booth when the final arrangement follows the supplied technical drawing, venue requirements, and engineering review.

What clamps fit this truss?

Use 35 mm clamps only. Standard 50 mm clamps will not fit the EVT290S main chords.

Are CAD files available?

STEP and DWG files are available upon request.

Is engineering available?

An engineering report is available as a separate service and should be requested during purchase.

Need a reusable 20x20 truss exhibit?

Contact us for assembly support, graphics and lighting planning, additional EVT290S components, engineering, CAD files, and quantity pricing.
